Solar Water Heater 100 Litre (Supreme Solar)
We offer Vacuum Tube High Efficiency Solar Collectors with PUF insulated Solar Water Tanks. Our tanks are also equipped with Assistant Tanks to prevent Hot and Cold water mixing – thereby increasing the efficiency of the systems. All our systems come with PUF Insulated High-Grade Steel for the inner tanks with the external tanks being powder coated/High-Grade Steel for increased life and aesthetics. This gives us the confidence to back our products with world class guarantees and warranties. Our systems come with All India 5 years’ replacement guarantee and 15 years warranty for the Vacuum Tubes.
Technical Features
- No scale formation
- No pipe blockage.
- High density compressed PUF Insulation to store hot water for upto 48 hrs.
- High transmissivity triple layered clog and choke free collector tubes.
- Suitable for bore well water and hard water usage.
Technical Specifications
SPECIFICATION |
|
| Warranty | 5 Years |
| Units/Package | 1 |
| In the box | 1 x Solar Water Heater 100 Litre with Electric Rod |
| Type of Collector | Evacuated Tube Collectors (ETC) |
| Tube Dimensions | 47 – 1800 mm or 58 – 1800 mm |
| Inner Tank Materials | High grade Stainless Steel |
| Outer Tank Materials | Stainless Steel / Powder Coated (Both Options Available) |
| Temperature | 65 degree C to 85 degree C |
| Method of Welding | Seam less and Non Welding Technology |
| Tank Insulation | High quality PUF materials |
| Tank Volume | 100 Ltr. |
| Frame Angle | 27 Degrees |
| Stand Frame | Galvanized Powder Coated |
| Type of Circulation | Thermo Siphon |
| Type of Grommets: | Silicon Rubbers |
| Model No. | 100 LPD |
