Solar Water Heater 100 Litre (Supreme Solar)
![GAMMA SERIES 10KVA - 400KVA Gama Series](images/products/solar-water-heater.jpg)
We offer Vacuum Tube High Efficiency Solar Collectors with PUF insulated Solar Water Tanks. Our tanks are also equipped with Assistant Tanks to prevent Hot and Cold water mixing – thereby increasing the efficiency of the systems. All our systems come with PUF Insulated High-Grade Steel for the inner tanks with the external tanks being powder coated/High-Grade Steel for increased life and aesthetics. This gives us the confidence to back our products with world class guarantees and warranties. Our systems come with All India 5 years’ replacement guarantee and 15 years warranty for the Vacuum Tubes.
Technical Features
- No scale formation
- No pipe blockage.
- High density compressed PUF Insulation to store hot water for upto 48 hrs.
- High transmissivity triple layered clog and choke free collector tubes.
- Suitable for bore well water and hard water usage.
Technical Specifications
SPECIFICATION |
|
Warranty | 5 Years |
Units/Package | 1 |
In the box | 1 x Solar Water Heater 100 Litre with Electric Rod |
Type of Collector | Evacuated Tube Collectors (ETC) |
Tube Dimensions | 47 – 1800 mm or 58 – 1800 mm |
Inner Tank Materials | High grade Stainless Steel |
Outer Tank Materials | Stainless Steel / Powder Coated (Both Options Available) |
Temperature | 65 degree C to 85 degree C |
Method of Welding | Seam less and Non Welding Technology |
Tank Insulation | High quality PUF materials |
Tank Volume | 100 Ltr. |
Frame Angle | 27 Degrees |
Stand Frame | Galvanized Powder Coated |
Type of Circulation | Thermo Siphon |
Type of Grommets: | Silicon Rubbers |
Model No. | 100 LPD |
