N310K Photovoltaic Module HIT Black (VBHN310KA01)
Panasonic’s N310K all-black module delivers outstanding performance, high output and enhanced aesthetics.
- Low Temperature Coefficient -0.258%/°C
- PID/LID Free
- 25 Year Product Workmanship Warranty / 25 Year Linear Power Output Warranty
Technical Features
- Powerful and High Efficiency Solar Panel
- High Efficiency Performance at High Temperatures
- Water Drainage Frame
- Light Capturing Technology
Technical Specifications
SPECIFICATION |
|
| Limited Warranty | 25 Years Workmanship, 25 Years Power Output |
| Rated Power (Pmax)1 | 310W |
| Maximum Power Current (Ipm) | 5.34A |
| Open Circuit Voltage (Voc) | 69.9V |
| Short Circuit Current (Isc) | 5.78A |
| Temperature Coefficient (Pmax) | -0.258%/°C |
| Temperature Coefficient (Voc) | -0. 174V/°C |
| Temperature Coefficient (Isc) | 1.79mA/°C |
| NOCT | 44.0°C |
| CEC PTC Rating | 292.1 |
| Cell Efficiency | 20.9% |
| Module Efficiency | 18.5% |
| Watts per Ft.2 | 17.2W |
| Maximum System Voltage | 600V |
| Series Fuse Rating | 15A |
| Warranted Tolerance (-/+) | +10%/-0%* |
| Internal Bypass Diodes | 4 Bypass Diodes |
| Module Area | 18.02 Ft.² (1.67m²) |
| Weight | 40.81 Lbs. (18.5kg) |
| Dimensions LxWxH | 62.6x41.5x1.4 in. (1590x1053x35 mm) |
| Cable Length +Male/-Female | 40.2/40.2 in. (1020/1020 mm) |
| Cable Size / Type | No. 12 AWG / PV Cable |
| Connector Type3 | Multi-Contact® Type IV (MC4™) |
| Static Wind / Snow Load | 50 PSF (2400 Pa) |
| Pallet Dimensions LxWxH | 63.7x42.2x5.5 in. (1618x1071x140 mm) |
| Quantity per 40’ Container | 560 pcs. |
| Quantity per 20’ Container | 240 pcs. |
